Arcam ST60 Network Music Streamer

Arcam ST60 Network Music Streamer

by Arcam
Save €390.00 Save €390.00
€1,599.00
€1,599.00 - €1,599.00
€1,599.00
€1,209.00
€1,209.00 - €1,209.00
€1,209.00

0 in stock
for immediate dispatch or click & collect
Available to order (with lead time)
For latest lead times or to put down a deposit please contact us
In a rush? See what's available for immediate dispatch

Effortless Streaming, Quality Sound

The ST60 is a high-performance streaming source that enables streaming audio from all of the major services (Tidal, Qobuz, Spotify, Napster, Deezer, etc) over Cast or Airplay2. It will also handle UPnP sources.

It is the perfect companion for the HDA range of stereo amplifiers and is also fully compatible with the MusicLife app.

Product Details

  • 4 digital inputs
  • Balanced XLR and Single ended RCA analogue outputs
  • Optical and coaxial digital outputs
  • GoogleCast, Airplay2, uPnP Streamer
  • Roon Ready certified
  • MQA supported
  • 32-bit ESS9038Q2M Sabre DAC
  • Full I/P and RS232 control including Control4 and Crestron
  • Total harmonic distortion + noise = 0.0008%

Specifications

Analogue Outputs

  • Digital to Analogue Conversion: ESS9038 32-bit/192kHz Delta-Sigma DAC
  • Signal/Noise Ratio (Awtd): 118dB unbalanced, 122db balanced
  • Harmonic Distortion (1kHz): <0.0008%
  • Frequency response: 10Hz – 20kHz ± 0.5dB
  • Output Level (Fixed): 2.2Vrms unbalanced, 4.5Vrms balanced
  • Output Impedance: 47Ω unbalanced, 600Ω balanced
  • Minimum Recommended Load: 5kΩ
  • RMS Jitter: < 20 psec

Digital Inputs

  • SPDIF Receiver: AKM4113
  • Supported sample rates (Optical): 32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz
  • Supported sample rates (Coaxial): 32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
  • Bit depth: 16-bit – 32-bit

Digital Interfaces

  • USB: USB 2.0 High Speed (480Mbps)
  • Ethernet: 10/100Mbps
  • Wireless: 802.11b/g/n

General

  • Mains voltage: 110–240V, 50–60Hz
  • Maximum power consumption: 10W
  • Low power standby consumption: 0.5W
  • Network standby consumption: 2W
  • Dimensions W x H x D (including feet and control knob): 433x102x306mm
  • Weight (net): 5.5kg
  • Weight (gross): 7.9kg
