Marantz Model 30 Integrated Amplifier

by Marantz
Original price €3,249.00
Original price €3,249.00 - Original price €3,249.00
Original price €3,249.00
Current price €2,499.00
€2,499.00 - €2,499.00
Current price €2,499.00

Availability: With lead time Lead times are estimates and will be confirmed with the supplier upon ordering. Our sales team will provide you with the actual lead time as soon as it is received.
Availability: With lead time Lead times are estimates and will be confirmed with the supplier upon ordering. Our sales team will provide you with the actual lead time as soon as it is received.
Color: Black

Get the most musical sound possible from the Marantz Model 30 Master-tuned integrated amplifier. Its custom-designed HDAM delivers exquisite detail and unforgettable musicality from any style of music.

Key Features

  • Tuned with passion: Hundreds of hours of thoughtful Sound Master tuning ensure the exquisite detail and musicality Marantz always delivers.
  • Designed to last: You see and feel it in the build quality and you hear it every time. No matter your musical passions, your music always sounds better with MODEL 30.
  • Fully discrete and accurate detailing: Marantz HDAM-SA3 technology is comprised of dozens of independent parts, each hand-selected for pure, detailed Marantz sound.
  • Extraordinary sensitivity: Designed to replicate the sensitivity and feel of a vintage analog amplifier even when simply adjusting the volume.

Exquisite sound tuning

MODEL 30 continues the renowned heritage of exquisite Marantz amplifiers. Tuned by the Marantz Sound Master who channeled his passion, experience, and extraordinary ear into the amplifier design.

The most musical, accurate, detailed sound

MODEL 30 is built on its own discrete circuit board, the Hyper-Dynamic Amplifier Module, or HDAM. By custom-curating hundreds of individual parts, rather than adopting an off-the-shelf solution, the MODEL 30 HDAM significantly outperforms standard integrated circuits to create the unique musicality you always expect from Marantz.

Marantz Musical Premium Phono EQ

Envisioned to deliver optimal sound quality by simplifying the signal path – vital given the delicate nature of phono signals – the Phono EQ stage in MODEL 30 can be used with both moving magnet and low-output moving coil cartridges, thanks to a built-in MC head amplifier.

The design lowers distortion, which is why the phono stage uses two-stage amplification, combining Marantz HDAMs with JFETs in the input stage, giving high input impedance. This allows the non-negative-feedback design to be further simplified by the deletion of coupling capacitors, again reducing distortion and enhancing signal purity.

MC / MM phono input impedance selector

In order to optimize sound performance when using a moving coil (MC) or magnetic moving (MM) cartridge, and to accommodate all configurations as much as possible, MODEL 30 is equipped with an input impedance selector. The input impedance can be adjusted to three different settings: MC Low (33 ohm), MC Mid (100 ohm), MC High (390 ohm).

Built for Generations

Like its counterpart, the SACD 30n Streaming CD Player, the MODEL 30 Integrated Amplifier is designed to the highest standards. The solid chassis is constructed from thick, heavy, non-magnetic aluminum panels and a rigid steel top cover to eliminate added interference. Sturdy, brass machined independent input terminals for CD and Phono plus Marantz original high-quality/high-purity nickel-plated speaker terminals ensure the best signal possible.

Features

Aluminium extrusion heat sink o (Separate)
Balance / Bass / Treble / Loudness o / o / o / -
Channels 2
Current Feedback Topology o
Customised Components o
Digital in: USB-B / optical / coaxial / USB-A - / - / - / -
HDAM version SA3, SA2
High Grade Audio Components o
Phono EQ: Standard / Marantz Musical / Marantz Musical Premium - / - / o
Power Transformer: Toroidal / El SMPS
Symmetric PCB Layout o


General

Auto power off o
Carton Maximum Dimensions (W x D x H) in mm 534 x 522 x 255
Carton Weight (inc. product) in kg 17.6
Detachable Power Cable o
Maximum Dimensions (W x D x H) in mm 443 x 431 x 130
Metal Front Panel o
Power Consumption in W 130
Remote Control RC002PMND
Standby Consumption in W 0.2
System Remote Function o
Weight in kg 14.8


Inputs/Outputs

Audio Inputs 6
Audio Outputs 1
Balanced In / Out - / -
D-Bus o
Digital in: USB-B / optical / coaxial / USB-A - / - / - / -
Floating Control Bus (3.5 mm mono jack x 2) -
Gold Plated Cinch o
HDMI: inputs / outputs -
Headphone Gain Control (low / mid / high) -
Headphone Out o
Number of terminals 2
Phono Input: MM / MC o / o
Power Amp Direct IN o
Pre-out / Main-in o / -
Speaker A / B -
Speaker Terminals Marantz SPKT-100+


Others

5mm aluminium top plate -
BI-AMP and Multichannel option -
Double Layer Bottom Plate o
Input buffer amp (all inputs / CD only) - / -
Linear Drive Power Supply o (pre-amplifier stage)
Liniear volume control o
Low noise LCD display -
Low Noise OELD display o
Marantz Musical Digital Filtering -
Power Amp direct -
Shottky diodes o
Source Direct -
System block shielding: copper / metal / none o / - / -


Specifications

Damping Factor 500
Frequency Response 5 Hz - 50kHz
Input Sensitivity: Balanced High level -
Input Sensitivity: High level 220 mV / 13 kohm
Input Sensitivity: MC 250
Input Sensitivity: MM 2.3 mV / 39 kohm
Input Sensitivity: Power Amp Direct IN -
Power Output (8 / 4 Ohm RMS) 100 W / 200 W
Signal to Noise Ratio: High level 107 dB(2V input/Rated output)
Signal to Noise Ratio: MM / MC 88 / 75 dB
Signal to Noise Ratio: Power Amp Direct IN -
Total Harmonic Distortion 0.005%
