Yamaha YAS209 Soundbar
Level up your TV sound. Enhance your TV, movies and games with built-in Alexa voice control, DTS® Virtual:X™ virtual 3D surround sound, a wireless subwoofer, and Bluetooth® streaming all in a simple, sleek setup.
- Built-in Alexa voice control for easy control of your sound bar, smart home devices, music and more
- Wireless subwoofer for deep bass with flexible placement
- Clear Voice for enhanced dialogue clarity
- DTS® Virtual:X™ virtual 3D surround sound
- Bluetooth® streaming for your music and podcasts
ALEXA VOICE CONTROL
“Alexa, turn the volume up in the lounge room.”
With Alexa voice control integration, all you have to do is ask. The YAS-209 offers built-in Alexa voice control for easy control of your sound bar, smart home devices, music and more.
*Availability of Amazon Alexa voice control varies by country.
IMMERSIVE 3D SOUND
Take your home cinema experience to new heights with sound that comes from above as well as all around you.
The YAS-209 features DTS Virtual:X – immersing the audience in exhilarating 3D surround sound from a single bar solution.
WIRELESS SUBWOOFER
A key benefit of having a sound bar is the ability to minimise clutter – eliminating the need for surround speakers and cables throughout a room.
A wireless subwoofer system takes this a step further by offering even greater flexibility in positioning. Experience explosive bass while enjoying the versatility of being able to place the subwoofer anywhere in the room.
| YAS-209 | ||
|---|---|---|
| Front Surround System | ||
| General | Drivers | Center unit: Front L/R: 4.6 cm (1-3/4”) cone × 4, Tweeter: 2.5 cm (1") dome × 2, Subwoofer: 16 cm (6-1/2”) cone |
| Output Power | 200 W (Center unit: 50 W × 2-ch, Subwoofer: 100 W) | |
| Power Consumption | Center unit: 25 W, 4.3 W (Voice Control Ready), Subwoofer: 20 W | |
| Standby Power Consumption | Center unit: 0.2 W (HDMI control off, network standby off), 1.6 / 1.8 / 1.7 W (HDMI control off, network standby on [Wired / Wi-Fi / Bluetooth®]), 0.6 W (HDMI control on, network standby off), 2.2 W (HDMI control on, network standby on), Subwoofer: 0.8 W | |
| Dimensions (W x H x D) | Center unit: 930 × 62 × 109 mm (36-5/8" × 2-1/2" × 4-1/4"), Subwoofer: 191 × 420 × 406 mm (7-1/2" × 16-1/2" × 16") | |
| Weight | Center unit: 2.7 kg (6 lbs), Subwoofer: 7.9 kg (17.4 lbs) | |
| Input / Output | HDMI | 1 in / 1 out |
| Digital Optical | 1 in | |
| HDMI | 4K Pass-through | Yes (50 / 60 Hz YCbCr=4:4:4, HDR10, HLG and HDCP2.3) |
| 3D Pass-through | Yes | |
| ARC | Yes | |
| CEC | Yes | |
| Auto Lip-Sync | Yes | |
| Sound Technology | Surround Technology | DTS® Virtual:X™ |
| Surround Mode | Music, TV program, Movie, Sports, Game | |
| Compressed Music Enhancer | Yes (for Bluetooth) | |
| Bass Extension | Yes | |
| Audio Formats | Dolby Digital | Yes |
| Dolby Pro Logic II | Yes | |
| DTS Digital Surround | Yes | |
| File Format | WAV (PCM format only) / FLAC: up to 192 kHz, ALAC: up to 96 kHz, MP3 / WMA / MPEG-4 AAC: up to 48 kHz | |
| Connectivity | Wireless Music Streaming | Yes |
| Wi-Fi | Yes (2.4 GHz) | |
| Bluetooth Version/Profile | Version: Ver 4.2 / Profiles: A2DP, AVRCP / Codecs: SBC, AAC | |
| Bluetooth Maximum Communication Range | Approx. 10 m ; 33ft (without obstructions) | |
| Wireless Subwoofer | Yes | |
| Other Features | App Control | Yes (Sound Bar Controller) |
